Used Holzher Edgebander 1057 Streamer

Used Holzher Edgebander – Model 1057 Streamer

Year: 2015

This used edgebander manufactured by Holz-Her features advanced technology with a CLOSED APPLICATION SYSTEM in which the glue is enclosed in an air-tight chamber and cannot oxidize, discolor, burn or become contaminated with wood dust. This allows for optimum glue adhesion… Additionally, the glue is applied to panel by a patented GLUE JET NOZZLE for panels 6-60 mm thick with precise control of all functions including begin and end.

Basic Machine Specifications:

• Pre-Milling (FG201) with diamond tooling
• Magazine for coil and strips (1903)
• GluJet-S with hybrid technology (GJ-201)
• Pressure Section (1912-3)
• 2 Motor End Trimming (1918P)
• Top and Bottom Trimming (FR201)
• Profile Scraping (1929) • Buffing (1940)
• Manual control panel
• Conveyor speed 10 m/min.
• Edge thickness 0.4 – 6 mm.
• Panel thickness 6 – 60 mm.
• One (1) centrally located hand wheel for raising and lowering of the top pressure beam.
• Fixed workpiece support at 380 mm
• Manual central lubrication of the transport chain

• Machine Requirement: 4425 mm / 174 in. 1410 mm / 56 in. 1610 mm / 63 in. 0.4 – 6 mm / .02 – .24 in. 65 mm / 2.5 in. Min. 350 mm (13.78 in) – Unlimited Min. 65 mm / 2.56 in 6 – 60mm / .23 – 2.36 in. 10 m/min / 32.81 ft
• Electronic Control System Pre-Milling SystemI (FG201)
• Patented ProLock clamping system for rapid tool changes
• Two powerful motors 200 Hz 12 000 rpm
• 2 diamond cuttersØ70x48x30mm
• 1x 1 2 Kw cutting counter-clockwise
• 1x 0 8 Kw cutting clockwise
• Manual adjustment for cutter head position
• Max. stock removal: Max. 3 mm milling on panels 6 -22 mm Max. 2 mm milling on panels 22-40 mm Max. 1 mm milling on panels 40-45 mm
• Edgefeed Magazine (1903)
• Fully automatic feed of coils and strips
• Utilizes motion detector to ensure accurately
• Trouble-free positioning of edge material.
• Exclusive “TRACTOR-BELT” feed system to ensure accurate trouble-free feeding of edge material as well as optimum operator safety.
• Magazine table on rollers for smooth feeding of coiled material.
• Automatic guillotine for coiled material up to 3.0 mm. Version 15.6
• Easily set glue temperature with dual controls
• Simple off/on control switches for all units
• Magazine selector switch for coiled or strip edgebanding
• Prominently positioned for easy access
• GluingStation – GluJet-S with hybrid technology (GJ-201)
• Fastest heat-up time in the industry 2 – 3 min.
• Fastest & easiest glue color change 5-10 min.
• Can utilize and process all glue types as standard (EVA, PUR,PO)
• Equipped with HOLZ-HER’S exclusive patented “CARTRIDGE” glue system.
